TECHNICAL DATA OF THE BMW 3 SERIES SEDAN.

Weight

Unladen weight EU in kg 1,545 [1,565]
Max. permissible weight in kg 2,050 [2,050]
Permitted load in kg 580 [560]
Permitted axle load front/rear in kg 965/1,160 [965/1,150]
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,300
Trailer load 12% (braked) in kg 1,300

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW at 1/min 115 /4,500-6,500
Engine torque (Nm) at 1/min 250/1,300-4,300
Compression ratio : 1 11.0

Performance

Top speed in km/h 223 [223]
Acceleration 0–100 km/h in s 8.9 [8.4]
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 9.4 [7.4]
Extra-urban in l/100 km 6.0 [5.6]
Combined in l/100 km 7.3 [6.3]
CO2 combined emissions in g/km 166 [143]
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 58-59

Wheels

Tyre dimensions front 205/60 R16 96 W XL
Tyre dimensions rear 205/60 R16 96 W XL
Wheel dimensions and material front 6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear 6.5 J x 16 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,570
Max. permissible weight in kg 2,050
Permitted load in kg 555
Permitted axle load front/rear in kg 965/1,150
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,600
Trailer load 12% (braked) in kg 1,600

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW at 1/min 135 /5,000-6,500
Engine torque (Nm) at 1/min 300/1,350-4,000
Compression ratio : 1 11.0

Performance

Top speed in km/h 235
Acceleration 0–100 km/h in s 7.1
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 7.4
Extra-urban in l/100 km 5.6
Combined in l/100 km 6.3
CO2 combined emissions in g/km 144
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 205/60 R16 96 W XL
Tyre dimensions rear 205/60 R16 96 W XL
Wheel dimensions and material front 6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear 6.5 J x 16 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,635
Max. permissible weight in kg 2,130
Permitted load in kg 570
Permitted axle load front/rear in kg 1,050/1,185
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW at 1/min 135 /5,000-6,500
Engine torque (Nm) at 1/min 300/1,350-4,000
Compression ratio : 1 11.0

Performance

Top speed in km/h 230
Acceleration 0–100 km/h in s 7.6
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 8.0
Extra-urban in l/100 km 6.1
Combined in l/100 km 6.8
CO2 combined emissions in g/km 155
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/50 R17 98 Y XL
Tyre dimensions rear 225/50 R17 98 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,580-1,545
Max. permissible weight in kg 2,060
Permitted load in kg 555-590
Permitted axle load front/rear in kg 985/1,160
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,600
Trailer load 12% (braked) in kg 1,600

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW at 1/min 190 /5,000-6,500
Engine torque (Nm) at 1/min 400/1,550-4,400
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 5.9-5.8
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 7.9
Extra-urban in l/100 km 5.8
Combined in l/100 km 6.6
CO2 combined emissions in g/km 150
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/50 R17 98 Y XL
Tyre dimensions rear 225/50 R17 98 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,660-1,640
Max. permissible weight in kg 2,155
Permitted load in kg 570-590
Permitted axle load front/rear in kg 1,055/1,195
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW at 1/min 190 /5,000-6,500
Engine torque (Nm) at 1/min 400/1,550-4,400
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 5.6-5.5
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 8.2
Extra-urban in l/100 km 6.2
Combined in l/100 km 6.9
CO2 combined emissions in g/km 158
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/50 R17 98 Y XL
Tyre dimensions rear 225/50 R17 98 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,810-1,745
Max. permissible weight in kg 2,245
Permitted load in kg 510-575
Permitted axle load front/rear in kg 1,115/1,230
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 94.6/82.0
Engine power in kW at 1/min 275-285 /5,500-6,500 - 5,800-6,500
Engine torque (Nm) at 1/min 500/1,800-5,000 - 1,900-5,000
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.4
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 10.0
Extra-urban in l/100 km 6.4
Combined in l/100 km 7.7
CO2 combined emissions in g/km 177
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/45 R18 95 Y XL
Tyre dimensions rear 255/40 R18 99 Y XL
Wheel dimensions and material front 7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,560 [1,615-1,580]
Max. permissible weight in kg 2,070 [2,115-2,080]
Permitted load in kg 585 [575]
Permitted axle load front/rear in kg 965/1,175 [965-995/1,175-1,180]
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,600
Trailer load 12% (braked) in kg 1,600

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power in kW at 1/min 85-90 /4,000
Engine torque (Nm) at 1/min 300/1,500-2,500 - 1,500-2,250
Compression ratio : 1 16.5

Performance

Top speed in km/h 206 [207]
Acceleration 0–100 km/h in s 9.9 [9.8-9.7]
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 5.9-5.8 [5.2]
Extra-urban in l/100 km 4.6-4.4 [4.4]
Combined in l/100 km 5.1-4.9 [4.7]
CO2 combined emissions in g/km 133-129 [124]
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 40-59

Wheels

Tyre dimensions front 205/60 R16 96 W XL
Tyre dimensions rear 205/60 R16 96 W XL
Wheel dimensions and material front 6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear 6.5 J x 16 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,560 [1,615-1,580]
Max. permissible weight in kg 2,075 [2,210-2,085]
Permitted load in kg 590 [580]
Permitted axle load front/rear in kg 965/1,180 [965-995/1,180-1,185]
Luggage capacity min. (seats up or roof down) in l 480 [480]
Luggage capacity max. (seats down or roof up) in l - [-]
Trailer load (unbraked) in kg 750 [750]
Trailer load 8% (braked) in kg 1,600 [1,600]
Trailer load 12% (braked) in kg 1,600 [1,600]

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power in kW at 1/min 100-110 /4,000-4,000
Engine torque (Nm) at 1/min 320/1,500-2,750 - 1,500-3,000
Compression ratio : 1 16.5

Performance

Top speed in km/h 220-226 [218-224]
Acceleration 0–100 km/h in s 9.0-8.4 [8.9-8.2]
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 5.8 [5.3-5.2]
Extra-urban in l/100 km 4.6 [4.6-4.5]
Combined in l/100 km 5.0 [4.8]
CO2 combined emissions in g/km 132 [127-125]
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 40-59

Wheels

Tyre dimensions front 205/60 R16 96 W XL
Tyre dimensions rear 205/60 R16 96 W XL
Wheel dimensions and material front 6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear 6.5 J x 16 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,570 [1,570]
Max. permissible weight in kg 2,075 [2,085]
Permitted load in kg 580 [590]
Permitted axle load front/rear in kg 970/1,180 [970/1,180]
Luggage capacity min. (seats up or roof down) in l 480 [480]
Luggage capacity max. (seats down or roof up) in l - [-]
Trailer load (unbraked) in kg 750 [750]
Trailer load 8% (braked) in kg 1,600 [1,600]
Trailer load 12% (braked) in kg 1,600 [1,600]

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power in kW at 1/min 120-140 /4,000-4,000
Engine torque (Nm) at 1/min 400/1,750-2,500 - 1,750-2,250
Compression ratio : 1 16.5

Performance

Top speed in km/h 227-240 [240]
Acceleration 0–100 km/h in s 7,8-7.1 [6.8]
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 5.7 [5.3]
Extra-urban in l/100 km 4.6 [4.5-4.4]
Combined in l/100 km 5.0 [4.8-4.7]
CO2 combined emissions in g/km 132 [127-124]
Electricity consumption, combined in kWh/100km - [-]
Tank capacity, approx. in l 40-59

Wheels

Tyre dimensions front 205/60 R16 96 W XL
Tyre dimensions rear 205/60 R16 96 W XL
Wheel dimensions and material front 6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear 6.5 J x 16 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,655
Max. permissible weight in kg 2,170
Permitted load in kg 590
Permitted axle load front/rear in kg 1,055/1,195
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power in kW at 1/min 140 /4,000-4,000
Engine torque (Nm) at 1/min 400/1,750-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 233
Acceleration 0–100 km/h in s 6.9
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 5.6-5.5
Extra-urban in l/100 km 4.8
Combined in l/100 km 5.1
CO2 combined emissions in g/km 134-133
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 40-59

Wheels

Tyre dimensions front 225/50 R17 98 Y XL
Tyre dimensions rear 225/50 R17 98 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,770
Max. permissible weight in kg 2,250
Permitted load in kg 555
Permitted axle load front/rear in kg 1,085/1,220
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW at 1/min 210 /4,000-4,000
Engine torque (Nm) at 1/min 650/1,500-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 5.3
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 6.3
Extra-urban in l/100 km 5.0
Combined in l/100 km 5.5
CO2 combined emissions in g/km 145
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/50 R17 98 Y XL
Tyre dimensions rear 225/50 R17 98 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,735
Max. permissible weight in kg 2,255
Permitted load in kg 595
Permitted axle load front/rear in kg 1,105/1,230
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW at 1/min 195 /4,000-4,000
Engine torque (Nm) at 1/min 580/1,750-2,750
Compression ratio : 1 16.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 5.1
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 6.6
Extra-urban in l/100 km 5.3
Combined in l/100 km 5.8
CO2 combined emissions in g/km 152
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/50 R17 98 Y XL
Tyre dimensions rear 225/50 R17 98 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,895
Max. permissible weight in kg 2,325
Permitted load in kg 505
Permitted axle load front/rear in kg 1,155/1,255
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW at 1/min 250 /4,400-4,400
Engine torque (Nm) at 1/min 700/1,750-2,250
Compression ratio : 1 16.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.6
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km -
Extra-urban in l/100 km -
Combined in l/100 km -
CO2 combined emissions in g/km -
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/45 R18 95 Y XL
Tyre dimensions rear 255/40 R18 99 Y XL
Wheel dimensions and material front 7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,840
Max. permissible weight in kg 2,300
Permitted load in kg 535
Permitted axle load front/rear in kg 1,035/1,315
Luggage capacity min. (seats up or roof down) in l 375
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,500
Trailer load 12% (braked) in kg 1,500

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW at 1/min 120 /5,000-6,500
Engine torque (Nm) at 1/min 300/1,350-3,700
Compression ratio : 1 11.0

Performance

Top speed in km/h 225
Acceleration 0–100 km/h in s 7.6
Top speed fully electric in km/h 140

Fuel consumption

Urban in l/100 km -
Extra-urban in l/100 km -
Combined in l/100 km -
CO2 combined emissions in g/km -
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 40

Wheels

Tyre dimensions front 225/50 R17 98 Y XL
Tyre dimensions rear 225/50 R17 98 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh 12.0
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h 2.6
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h 3.6

Electric engine

Electric engine power kW at 1/min 83 /3,170
Electric Engine torque (Nm) at 1/min 265/100-2,500

Combined system power

Combined power kW 150
Combined torque Nm 350

Weight

Unladen weight EU in kg 1,845
Max. permissible weight in kg 2,300
Permitted load in kg 530
Permitted axle load front/rear in kg 1,035/1,315
Luggage capacity min. (seats up or roof down) in l 375
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,500
Trailer load 12% (braked) in kg 1,500

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW at 1/min 135 /5,000-6,500
Engine torque (Nm) at 1/min 300/1,350-4,000
Compression ratio : 1 11.0

Performance

Top speed in km/h 230
Acceleration 0–100 km/h in s 5.8
Top speed fully electric in km/h 140

Fuel consumption

Urban in l/100 km -
Extra-urban in l/100 km -
Combined in l/100 km 2.1
CO2 combined emissions in g/km 48
Electricity consumption, combined in kWh/100km 16.9
Tank capacity, approx. in l 40

Wheels

Tyre dimensions front 225/50 R17 98 Y XL
Tyre dimensions rear 225/50 R17 98 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh 12.0
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h 2.6
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h 3.6

Electric engine

Electric engine power kW at 1/min 83 /3,170
Electric Engine torque (Nm) at 1/min 265/100-2,500

Combined system power

Combined power kW 215
Combined torque Nm 420

Weight

Unladen weight EU in kg 1,895
Max. permissible weight in kg 2,360
Permitted load in kg 540
Permitted axle load front/rear in kg 1,090/1,325
Luggage capacity min. (seats up or roof down) in l 375
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,500
Trailer load 12% (braked) in kg 1,500

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW at 1/min 135 /5,000-6,500
Engine torque (Nm) at 1/min 300/1,350-4,000
Compression ratio : 1 11.0

Performance

Top speed in km/h 230
Acceleration 0–100 km/h in s 5.8
Top speed fully electric in km/h 140

Fuel consumption

Urban in l/100 km -
Extra-urban in l/100 km -
Combined in l/100 km -
CO2 combined emissions in g/km -
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 40

Wheels

Tyre dimensions front 225/50 R17 98 Y XL
Tyre dimensions rear 225/50 R17 98 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh 12.0
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h 2.6
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h 3.6

Electric engine

Electric engine power kW at 1/min 83 /3,170
Electric Engine torque (Nm) at 1/min 265/100-2,500

Combined system power

Combined power kW 215
Combined torque Nm 420
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.
