BMW 3 Series Sedan (G20), technical data

THE 3

THE BMW 3 SERIES SEDAN: ENGINES & TECHNICAL DATA

Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW 3 Series Sedan.

Read more
THE 3THE BMW 3 SERIES SEDAN: ENGINES & TECHNICAL DATA

TECHNICAL DATA OF THE BMW 3 SERIES SEDAN.

Weight

Unladen weight EU in kg 1,545 [1,565]
Max. permissible weight in kg 2,050 [2,050]
Permitted load in kg 580 [560]
Permitted axle load front/rear in kg 965/1,160 [965/1,150]
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,300
Trailer load 12% (braked) in kg 1,300

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW at 1/min 115 /4,500-6,500
Engine torque (Nm) at 1/min 250/1,300-4,300
Compression ratio : 1 11.0

Performance

Top speed in km/h 223 [223]
Acceleration 0–100 km/h in s 8.9 [8.4]
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 9.4 [7.4]
Extra-urban in l/100 km 6.0 [5.6]
Combined in l/100 km 7.3 [6.3]
CO2 combined emissions in g/km 166 [143]
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 58-59

Wheels

Tyre dimensions front 205/60 R16 96 W XL
Tyre dimensions rear 205/60 R16 96 W XL
Wheel dimensions and material front 6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear 6.5 J x 16 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW -
Combined torque Nm -
