Technical data for the BMW M235 xDrive Gran Coupé.

¹
Powertrain type	Petrol
Power in kW	115 (156)
Torque in Nm	230
Transmission	7-speed, automatic
Drivetrain	Front-wheel drive

¹
Cylinders	3
Displacement in cm³	1,499
Nominal power in kW/1rpm	115 (156) / 4,900 - 6,500
Nominal torque in Nm/1rpm	230 / 1,500 - 4,600


Acceleration 0–100 km/h in s	8.6
Top speed in km/h	230

^{1 ,} ²
Combined in l/100km	6.3
Combined in g/km	143


4,546 mm
1,800 mm
1,445 mm
Length in mm	4,546
Width in mm	1,800
Height in mm	1,445
Width incl. mirrors (driver / passenger side) in mm	2,070
Wheelbase in mm	2,670
Vehicle curb weight in kg ³	1,495
Permissible gross weight in kg	1,950
Payload in kg	530
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁴	1,300 / 75
Luggage capacity in l	430
Tank capacity in l	49

¹
Powertrain type	Petrol
Power in kW	150 (204)
Torque in Nm	300
Transmission	7-speed, automatic
Drivetrain	Front-wheel drive

¹
Cylinders	4
Displacement in cm³	1,998
Nominal power in kW/1rpm	150 (204) / 5,000 - 6,500
Nominal torque in Nm/1rpm	300 / 1,450 - 4,500


Acceleration 0–100 km/h in s	7.3
Top speed in km/h	250

^{1 ,} ²
Combined in l/100km	6.7
Combined in g/km	152


4,546 mm
1,800 mm
1,445 mm
Length in mm	4,546
Width in mm	1,800
Height in mm	1,445
Width incl. mirrors (driver / passenger side) in mm	2,070
Wheelbase in mm	2,670
Vehicle curb weight in kg ³	1,525
Permissible gross weight in kg	2,005
Payload in kg	555
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁴	1,300 / 75
Luggage capacity in l	430
Tank capacity in l	49

¹
Powertrain type	Petrol
Power in kW	233 (317)
Torque in Nm	400
Transmission	7-speed, automatic
Drivetrain	All-wheel drive

¹
Cylinders	4
Displacement in cm³	1,998
Nominal power in kW/1rpm	233 (317) / 5,750 - 6,500
Nominal torque in Nm/1rpm	400 / 2,000 - 4,500


Acceleration 0–100 km/h in s	4.9
Top speed in km/h	250

^{1 ,} ²
Combined in l/100km	7.7
Combined in g/km	176


4,546 mm
1,800 mm
1,445 mm
Length in mm	4,546
Width in mm	1,800
Height in mm	1,445
Width incl. mirrors (driver / passenger side) in mm	2,070
Wheelbase in mm	2,670
Vehicle curb weight in kg ³	1,650
Permissible gross weight in kg	2,130
Payload in kg	555
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁴	750 / 75
Luggage capacity in l	430
Tank capacity in l	49

¹
Powertrain type	Petrol
Power in kW	125
Torque in Nm	280
Transmission	7-Gang, automatisch
Drivetrain	Rear-wheel drive

¹
Cylinders	3
Displacement in cm³	1,499
Nominal power in kW/1rpm	115/4,700–6,500
Nominal torque in Nm/1rpm	240/1,500–4,400


(Nominal) power/30-minutes-power in kW (hp)	15/9
(Nominal) torque in Nm	55


Acceleration 0–100 km/h in s	7.9
Top speed in km/h	230

^{1 ,} ²
Combined in l/100km	5.7–5.2
Combined in g/km	129–119
Pass-by noise in dB(A)	67
Stationary noise level in dB(A) / 1/min	78/3,750


Battery capacity in kWh	0.9


4,546 mm
1,800 mm
1,445 mm
Length in mm	4,546
Width in mm	1,800
Height in mm	1,445
Wheelbase in mm	2,670
Vehicle curb weight in kg ³	1,525
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ⁴	1,300/75
Luggage capacity in l	360
Tank capacity in l	49

1 Performance data of petrol engines apply to vehicles using RON 98 fuel. Fuel consumption data apply to vehicles using reference fuels in accordance with EU Regulation 715/2007. Unleaded RON 91 and higher with a maximum ethanol content of 10% (E10) may also be used. BMW recommends RON 95 fuel. For high-performance automobiles, BMW recommends RON 98 fuel.

2 Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp

3 The EC unladen weight refers to a vehicle with standard equipment and does not include any optional extras. The unladen weight includes a 90% full tank and a driver weight of 75 kg. Optional equipment may affect the weight of the vehicle, the payload and the top speed if the selected equipment has an impact on the vehicle's aerodynamics.

4 Trailer load depends on the vehicle options.
