BMW 2 SERIES GRAN COUPÉ: TECHNICAL DATA.
Discover the powerful petrol and diesel engines as well as the dimensions and other technical data of the BMW 2 Series Gran Coupé.
Discover the powerful petrol and diesel engines as well as the dimensions and other technical data of the BMW 2 Series Gran Coupé.
BMW 2 SERIES GRAN COUPÉ: TECHNICAL DATA.
No search result found. Please try another input
Fuel type | Petrol |
---|---|
System power in kW | 103 (140) |
Max. Torque (Nm) | 220 |
Gearbox | 7-speed, automatic |
Drive Type | Front wheel drive |
Cylinder/ Valves per cylinder | 3 / 4 |
---|---|
Technical capacity in cm3 | 1,499 |
Internal combustion engine power in kW | 103 (140) / 4600 - 6500 |
Max torque(Nm) per 1/min | 220 / 1480 - 4200 |
Top Speed | 213 |
---|---|
Acceleration | 8.7 |
Length/Width/Height | 4,526 / 1,800 / 1,420 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2081 (1045 / 1036) |
Wheelbase in mm/Wheel turn in m | 2,670 / 11.4 |
Ground clearance in mm | 152 |
Weight not loaded in kg | 1,450 |
---|---|
Weight Max in kg | 1,905 |
Permitted load in kg | 530 |
Permitted Axel load front/rear in kg | 1,025 / 970 |
Allowed unbraked trailer load / drawbar load in kg | 715 / 75 |
Allowed braked trailer load up to 12 % / 8 % incline in kg | 1,300 |
Trunk capacity min.-max. in l | 430 |
Tire front | 235/35 R19 91 Y XL |
---|---|
Tire rear | 235/35 R19 91 Y XL |
Rim front | 8Jx19 LM |
Rim rear | 8Jx19 LM |
Consumption overall in l/100km | 5.9 |
---|---|
Co2 overall in g/km | 135 |
Tank capacity in l | 50 |
Fuel type | Petrol |
---|---|
System power in kW | 141 (192) |
Max. Torque (Nm) | 280 |
Gearbox | 7-speed, automatic |
Drive Type | Front wheel drive |
Cylinder/ Valves per cylinder | 4 / 4 |
---|---|
Technical capacity in cm3 | 1,998 |
Internal combustion engine power in kW | 141 (192) / 5000 - 6000 |
Max torque(Nm) per 1/min | 280 / 1350 - 4600 |
Top Speed | 238 |
---|---|
Acceleration | 7.1 |
Length/Width/Height | 4,526 / 1,800 / 1,420 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2081 (1045 / 1036) |
Wheelbase in mm/Wheel turn in m | 2,670 / 11.4 |
Ground clearance in mm | 152 |
Weight not loaded in kg | 1,505 |
---|---|
Weight Max in kg | 1,965 |
Permitted load in kg | 535 |
Permitted Axel load front/rear in kg | 1,060 / 980 |
Allowed unbraked trailer load / drawbar load in kg | 750 / 75 |
Allowed braked trailer load up to 12 % / 8 % incline in kg | 1,300 |
Trunk capacity min.-max. in l | 430 |
Tire front | 235/35 R19 91 Y XL |
---|---|
Tire rear | 235/35 R19 91 Y XL |
Rim front | 8Jx19 LM |
Rim rear | 8Jx19 LM |
Consumption overall in l/100km | 6.3 |
---|---|
Co2 overall in g/km | 145 |
Tank capacity in l | 50 |
Fuel type | Petrol |
---|---|
System power in kW | 225 (306) |
Max. Torque (Nm) | 450 |
Gearbox | 8-speed, automatic |
Drive Type | All wheel drive |
Cylinder/ Valves per cylinder | 4 / 4 |
---|---|
Technical capacity in cm3 | 1,998 |
Internal combustion engine power in kW | 225 (306) / 5000 - 6250 |
Max torque(Nm) per 1/min | 450 / 1750 - 4500 |
Top Speed | 250 |
---|---|
Acceleration | 4.9 |
Length/Width/Height | 4,526 / 1,800 / 1,420 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2081 (1045 / 1036) |
Wheelbase in mm/Wheel turn in m | 2,670 / 11.4 |
Ground clearance in mm | 152 |
Weight not loaded in kg | 1,645 |
---|---|
Weight Max in kg | 2,105 |
Permitted load in kg | 535 |
Permitted Axel load front/rear in kg | 1,140 / 1,040 |
Trunk capacity min.-max. in l | 430 |
Tire front | 225/40 R18 92 Y XL |
---|---|
Tire rear | 225/40 R18 92 Y XL |
Rim front | 8Jx18 LM |
Rim rear | 8Jx18 LM |
Consumption overall in l/100km | 7.6 |
---|---|
Co2 overall in g/km | 173 |
Tank capacity in l | 50 |
Fuel consumption and CO2 emissions.
BMW M235i xDrive Gran Coupé:
Fuel consumption in l/100 km (combined): 7.8–7.2
CO2 emissions in g/km (combined): 175–162
Official data on fuel consumption, CO2 emissions, power consumption and electric range were determined in accordance with the mandatory measurement procedure and comply with Regulation (EU) 715/2007 valid at the time of type approval. In case of a range, figures in the WLTP take into account any optional equipment. For newly type-tested vehicles since 01.01.2021, the official data no longer exist according to NEDC, but only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
