BMW 5 SERIES SEDAN: TECHNICAL DATA.

Select a model

Weight

Unladen weight EU in kg 1610
Max. permissible weight in kg 2.285
Permitted load in kg 675
Permitted axle load front/rear in kg 1.080/1.280
Luggage capacity min. (seats up or roof down) in l 530
Luggage capacity max. (seats down or roof up) in l -

Engine

Cylinders/valves 4/4
Capacity in ccm 1.998
Stroke/bore in mm 94,6/82,0
Engine power in kW (hp) at 1/min 135/5.000-6.500
Engine torque (Nm) at 1/min 290/1.350-4.250
Compression ratio : 1 11,0

Performance

Top speed in km/h 235
Acceleration 0–100 km/h in s 7,8
Electrical engine top speed in km/h -

Fuel consumption

Urban in l/100 km 8,5
Extra-urban in l/100 km 5,8
Combined in l/100 km 6,8
CO2 combined emissions in g/km 156
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 245/40 R 19
Tyre dimensions rear 275/35 R 19
Wheel dimensions and material front 8J × 19
Wheel dimensions and material rear 9J × 19

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1625
Max. permissible weight in kg 2.305
Permitted load in kg 680
Permitted axle load front/rear in kg 1.090/1.300
Luggage capacity min. (seats up or roof down) in l 530
Luggage capacity max. (seats down or roof up) in l -

Engine

Cylinders/valves 4/4
Capacity in ccm 1.998
Stroke/bore in mm 94,6/82,0
Engine power in kW (hp) at 1/min 185/5.200-6.500
Engine torque (Nm) at 1/min 350/1.450-4.800
Compression ratio : 1 10,2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 6,1
Electrical engine top speed in km/h -

Fuel consumption

Urban in l/100 km 8,1
Extra-urban in l/100 km 5,9
Combined in l/100 km 6,7
CO2 combined emissions in g/km 154
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 245/40 R 19
Tyre dimensions rear 275/35 R 19
Wheel dimensions and material front 8J × 19
Wheel dimensions and material rear 9J × 19

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1915
Max. permissible weight in kg 2.560
Permitted load in kg 645
Permitted axle load front/rear in kg 1.260/1.365
Luggage capacity min. (seats up or roof down) in l 530
Luggage capacity max. (seats down or roof up) in l -

Engine

Cylinders/valves 8/4
Capacity in ccm 4.395
Stroke/bore in mm 88,3/89,0
Engine power in kW (hp) at 1/min 390 /5.500-6.000
Engine torque (Nm) at 1/min 750/1.800-4.600
Compression ratio : 1 10,5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 3.8
Electrical engine top speed in km/h -

Fuel consumption

Urban in l/100 km 14,9
Extra-urban in l/100 km 8,3
Combined in l/100 km 10,7
CO2 combined emissions in g/km 246
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 245/35 R 20
Tyre dimensions rear 275/30 R 20
Wheel dimensions and material front 8 J × 20
Wheel dimensions and material rear 9 J × 20

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1760
Max. permissible weight in kg 2.355
Permitted load in kg 595
Permitted axle load front/rear in kg 1.135/1.315
Luggage capacity min. (seats up or roof down) in l 530
Luggage capacity max. (seats down or roof up) in l -

Engine

Cylinders/valves 6/4
Capacity in ccm 2.993
Stroke/bore in mm 90,0/84,0
Engine power in kW (hp) at 1/min 195 /4.000
Engine torque (Nm) at 1/min 620/2.000-2.500
Compression ratio : 1 16,5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 5,7
Electrical engine top speed in km/h -

Fuel consumption

Urban in l/100 km 6,7
Extra-urban in l/100 km 5,2-4,8
Combined in l/100 km 5,5
CO2 combined emissions in g/km 145
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 66

Wheels

Tyre dimensions front 245/40 R 19
Tyre dimensions rear 275/35 R 19
Wheel dimensions and material front 8J × 19
Wheel dimensions and material rear 9J × 19

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1835
Max. permissible weight in kg 2.505
Permitted load in kg 670
Permitted axle load front/rear in kg 1.120/1.450
Luggage capacity min. (seats up or roof down) in l 410
Luggage capacity max. (seats down or roof up) in l -

Engine

Cylinders/valves 4/4
Capacity in ccm 1.998
Stroke/bore in mm 94,6/82,0
Engine power in kW (hp) at 1/min 215 /5.000-6.500
Engine torque (Nm) at 1/min 300/1.350-4.000
Compression ratio : 1 11,0

Performance

Top speed in km/h 235
Acceleration 0–100 km/h in s 5,9
Electrical engine top speed in km/h 140

Fuel consumption

Urban in l/100 km -
Extra-urban in l/100 km -
Combined in l/100 km 2.3
CO2 combined emissions in g/km 53
Electricity consumption, combined in kWh/100km 17,6
Tank capacity, approx. in l 46

Wheels

Tyre dimensions front 245/40 R 19
Tyre dimensions rear 275/35 R 19
Wheel dimensions and material front 8J × 19
Wheel dimensions and material rear 9J × 19

Range and charging

Electric range in km 54
Growth capacity of lithium-ion battery in kWh 12,0
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h 2.6
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h 3,6

Electric engine

Electric engine power kW (hp) at 1/min 80 /3.140
Electric Engine torque (Nm) at 1/min 265/100-2.500

Combined system power

Combined power kW (hp) 215
Combined torque Nm 420
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW 530e**:
Fuel consumption in l/100 km (combined): 1,8–1,3
CO2 emissions in g/km (combined): 41–30



Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp



** At temperatures below 0 degrees Celsius, purely electric driving mode of this plug-in hybrid will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few kilometers.
