THE 5
BMW 5 SERIES SEDAN: ENGINES &
TECHNICAL DATA.
Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW 5 Series Sedan.
Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW 5 Series Sedan.
BMW 5 SERIES SEDAN: TECHNICAL DATA.
- BMW 520i Sedan
- BMW 530i Sedan
- BMW M550i xDrive Sedan
- BMW 530d Sedan
- BMW 530e Sedan
No search result found. Please try another input

Unladen weight EU in kg | 1610 |
---|---|
Max. permissible weight in kg | 2.285 |
Permitted load in kg | 675 |
Permitted axle load front/rear in kg | 1.080/1.280 |
Luggage capacity min. (seats up or roof down) in l | 530 |
Luggage capacity max. (seats down or roof up) in l | - |
Cylinders/valves | 4/4 |
---|---|
Capacity in ccm | 1.998 |
Stroke/bore in mm | 94,6/82,0 |
Engine power in kW (hp) at 1/min | 135/5.000-6.500 |
Engine torque (Nm) at 1/min | 290/1.350-4.250 |
Compression ratio : 1 | 11,0 |
Top speed in km/h | 235 |
---|---|
Acceleration 0–100 km/h in s | 7,8 |
Electrical engine top speed in km/h | - |
Urban in l/100 km | 8,5 |
---|---|
Extra-urban in l/100 km | 5,8 |
Combined in l/100 km | 6,8 |
CO2 combined emissions in g/km | 156 |
Electricity consumption, combined in kWh/100km | - |
Tank capacity, approx. in l | 68 |
Tyre dimensions front | 245/40 R 19 |
---|---|
Tyre dimensions rear | 275/35 R 19 |
Wheel dimensions and material front | 8J × 19 |
Wheel dimensions and material rear | 9J × 19 |
Electric range in km | - |
---|---|
Growth capacity of lithium-ion battery in kWh | - |
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
Electric engine power kW (hp) at 1/min | - |
---|---|
Electric Engine torque (Nm) at 1/min | - |
Combined power kW (hp) | - |
---|---|
Combined torque Nm | - |
Unladen weight EU in kg | 1625 |
---|---|
Max. permissible weight in kg | 2.305 |
Permitted load in kg | 680 |
Permitted axle load front/rear in kg | 1.090/1.300 |
Luggage capacity min. (seats up or roof down) in l | 530 |
Luggage capacity max. (seats down or roof up) in l | - |
Cylinders/valves | 4/4 |
---|---|
Capacity in ccm | 1.998 |
Stroke/bore in mm | 94,6/82,0 |
Engine power in kW (hp) at 1/min | 185/5.200-6.500 |
Engine torque (Nm) at 1/min | 350/1.450-4.800 |
Compression ratio : 1 | 10,2 |
Top speed in km/h | 250 |
---|---|
Acceleration 0–100 km/h in s | 6,1 |
Electrical engine top speed in km/h | - |
Urban in l/100 km | 8,1 |
---|---|
Extra-urban in l/100 km | 5,9 |
Combined in l/100 km | 6,7 |
CO2 combined emissions in g/km | 154 |
Electricity consumption, combined in kWh/100km | - |
Tank capacity, approx. in l | 68 |
Tyre dimensions front | 245/40 R 19 |
---|---|
Tyre dimensions rear | 275/35 R 19 |
Wheel dimensions and material front | 8J × 19 |
Wheel dimensions and material rear | 9J × 19 |
Electric range in km | - |
---|---|
Growth capacity of lithium-ion battery in kWh | - |
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
Electric engine power kW (hp) at 1/min | - |
---|---|
Electric Engine torque (Nm) at 1/min | - |
Combined power kW (hp) | - |
---|---|
Combined torque Nm | - |
Unladen weight EU in kg | 1915 |
---|---|
Max. permissible weight in kg | 2.560 |
Permitted load in kg | 645 |
Permitted axle load front/rear in kg | 1.260/1.365 |
Luggage capacity min. (seats up or roof down) in l | 530 |
Luggage capacity max. (seats down or roof up) in l | - |
Cylinders/valves | 8/4 |
---|---|
Capacity in ccm | 4.395 |
Stroke/bore in mm | 88,3/89,0 |
Engine power in kW (hp) at 1/min | 390 /5.500-6.000 |
Engine torque (Nm) at 1/min | 750/1.800-4.600 |
Compression ratio : 1 | 10,5 |
Top speed in km/h | 250 |
---|---|
Acceleration 0–100 km/h in s | 3.8 |
Electrical engine top speed in km/h | - |
Urban in l/100 km | 14,9 |
---|---|
Extra-urban in l/100 km | 8,3 |
Combined in l/100 km | 10,7 |
CO2 combined emissions in g/km | 246 |
Electricity consumption, combined in kWh/100km | - |
Tank capacity, approx. in l | 68 |
Tyre dimensions front | 245/35 R 20 |
---|---|
Tyre dimensions rear | 275/30 R 20 |
Wheel dimensions and material front | 8 J × 20 |
Wheel dimensions and material rear | 9 J × 20 |
Electric range in km | - |
---|---|
Growth capacity of lithium-ion battery in kWh | - |
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
Electric engine power kW (hp) at 1/min | - |
---|---|
Electric Engine torque (Nm) at 1/min | - |
Combined power kW (hp) | - |
---|---|
Combined torque Nm | - |
Unladen weight EU in kg | 1760 |
---|---|
Max. permissible weight in kg | 2.355 |
Permitted load in kg | 595 |
Permitted axle load front/rear in kg | 1.135/1.315 |
Luggage capacity min. (seats up or roof down) in l | 530 |
Luggage capacity max. (seats down or roof up) in l | - |
Cylinders/valves | 6/4 |
---|---|
Capacity in ccm | 2.993 |
Stroke/bore in mm | 90,0/84,0 |
Engine power in kW (hp) at 1/min | 195 /4.000 |
Engine torque (Nm) at 1/min | 620/2.000-2.500 |
Compression ratio : 1 | 16,5 |
Top speed in km/h | 250 |
---|---|
Acceleration 0–100 km/h in s | 5,7 |
Electrical engine top speed in km/h | - |
Urban in l/100 km | 6,7 |
---|---|
Extra-urban in l/100 km | 5,2-4,8 |
Combined in l/100 km | 5,5 |
CO2 combined emissions in g/km | 145 |
Electricity consumption, combined in kWh/100km | - |
Tank capacity, approx. in l | 66 |
Tyre dimensions front | 245/40 R 19 |
---|---|
Tyre dimensions rear | 275/35 R 19 |
Wheel dimensions and material front | 8J × 19 |
Wheel dimensions and material rear | 9J × 19 |
Electric range in km | - |
---|---|
Growth capacity of lithium-ion battery in kWh | - |
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
Electric engine power kW (hp) at 1/min | - |
---|---|
Electric Engine torque (Nm) at 1/min | - |
Combined power kW (hp) | - |
---|---|
Combined torque Nm | - |
Unladen weight EU in kg | 1835 |
---|---|
Max. permissible weight in kg | 2.505 |
Permitted load in kg | 670 |
Permitted axle load front/rear in kg | 1.120/1.450 |
Luggage capacity min. (seats up or roof down) in l | 410 |
Luggage capacity max. (seats down or roof up) in l | - |
Cylinders/valves | 4/4 |
---|---|
Capacity in ccm | 1.998 |
Stroke/bore in mm | 94,6/82,0 |
Engine power in kW (hp) at 1/min | 215 /5.000-6.500 |
Engine torque (Nm) at 1/min | 300/1.350-4.000 |
Compression ratio : 1 | 11,0 |
Top speed in km/h | 235 |
---|---|
Acceleration 0–100 km/h in s | 5,9 |
Electrical engine top speed in km/h | 140 |
Urban in l/100 km | - |
---|---|
Extra-urban in l/100 km | - |
Combined in l/100 km | 2.3 |
CO2 combined emissions in g/km | 53 |
Electricity consumption, combined in kWh/100km | 17,6 |
Tank capacity, approx. in l | 46 |
Tyre dimensions front | 245/40 R 19 |
---|---|
Tyre dimensions rear | 275/35 R 19 |
Wheel dimensions and material front | 8J × 19 |
Wheel dimensions and material rear | 9J × 19 |
Electric range in km | 54 |
---|---|
Growth capacity of lithium-ion battery in kWh | 12,0 |
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | 2.6 |
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | 3,6 |
Electric engine power kW (hp) at 1/min | 80 /3.140 |
---|---|
Electric Engine torque (Nm) at 1/min | 265/100-2.500 |
Combined power kW (hp) | 215 |
---|---|
Combined torque Nm | 420 |
FUEL CONSUMPTION AND CO2 EMISSIONS.
BMW 530e**:
Fuel consumption in l/100 km (combined): 1,8–1,3
CO2 emissions in g/km (combined): 41–30
Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
** At temperatures below 0 degrees Celsius, purely electric driving mode of this plug-in hybrid will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few kilometers.
