BMW iX M60: ENGINE & TECHNICAL DATA

THE iX M60BMW iX M60: ENGINE & TECHNICAL DATA

The key facts and figures for the BMW iX M60 at a glance:


  • Motor, electric range, electricity consumption, charging and CO2 emissions
  • Performance data such as displacement, hp, Nm and acceleration
  • Weight, dimensions, wheel and tyre sizes
THE iX M60
Build & Price

ENGINE AND TECHNICAL DATA OF THE BMW iX M60.

Select model
Select Transmission

System Power

Powertrain type Electric
Power in Kw 240 (326)
Torque in Nm 630
Gearbox 1-speed, automatic
Drivetrain All-wheel drive

BMW eDrive

Continous power in kW (hp) 102 (139)
Nominal torque in Nm 630

Performance

Maximum speed in km/h 200
Acceleration 0–100 km/h in s 6.1

Measurements

Length/Width/Height 4,953 / 1,967 / 1,695
Width incl. mirrors (driver / passenger side) in mm 2230 (1118 / 1112)
Wheelbase in mm 3,000 / 12.8
Ground clearance in mm 202

Weight

Curb weight in kg 2,440
Maximum weight in kg 3,010
Permitted load in kg 645
Permitted Axel load front/rear in kg 1,450 / 1,690
Allowed unbraked trailer load / drawbar load in kg 750 / 100
Luggage capacity in l 500 - 1750

Wheels

Tire front 235/60 R20 108 H XL
Tire rear 235/60 R20 108 H XL
Rim front 8,5Jx20 LM
Rim rear 8,5Jx20 LM

System Power

Powertrain type Electric
Power in Kw 385 (523)
Torque in Nm 765
Gearbox 1-speed, automatic
Drivetrain All-wheel drive

BMW eDrive

Continous power in kW (hp) 140 (190)
Nominal torque in Nm 765

Performance

Maximum speed in km/h 200
Acceleration 0–100 km/h in s 4.6

Measurements

Length/Width/Height 4,953 / 1,967 / 1,696
Width incl. mirrors (driver / passenger side) in mm 2230 (1118 / 1112)
Wheelbase in mm 3,000 / 12.8
Ground clearance in mm 203

Weight

Curb weight in kg 2,585
Maximum weight in kg 3,145
Permitted load in kg 635
Permitted Axel load front/rear in kg 1,530 / 1,780
Allowed unbraked trailer load / drawbar load in kg 750 / 100
Luggage capacity in l 500 - 1750

Wheels

Tire front 275/40 R22 107 Y XL
Tire rear 275/40 R22 107 Y XL
Rim front 9,5Jx22 LM
Rim rear 9,5Jx22 LM

System Power

Powertrain type Electric
Gearbox 1-speed, automatic
Drivetrain All-wheel drive

System Power

Powertrain type Electric
Gearbox 1-speed, automatic

Range Charging

Battery capacity in kWh 74.1

System Power

Powertrain type Electric
Gearbox 1-speed, automatic

Range Charging

Battery capacity in kWh 108.8

System Power

Powertrain type Electric
Gearbox 1-speed, automatic

Range Charging

Battery capacity in kWh 108.6
