THE NEW BMW 3 SERIES SEDAN M Models: ENGINES & TECHNICAL DATA.
The new BMW 3 Series Sedan M Models – engines, facts and dimensions.
BMW 3 SERIES SEDAN M MODELS: TECHNICAL DATA.
No search result found. Please try another input
Fuel type | Petrol |
---|---|
System power in kW | 375 (510) |
Max. Torque (Nm) | 650 |
Gearbox | 8-speed, automatic |
Drive Type | All wheel drive |
Cylinder/ Valves per cylinder | 6 / 4 |
---|---|
Technical capacity in cm3 | 2,993 |
Internal combustion engine power in kW | 375 (510) / 6,250 |
Max torque(Nm) per 1/min | 650 / 2750 - 5500 |
Top Speed | 250 |
---|---|
Acceleration | 3.5 |
Length/Width/Height | 4,794 / 1,903 / 1,434 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2068 (1040 / 1028) |
Wheelbase in mm/Wheel turn in m | 2,857 / 12.6 |
Ground clearance in mm | 122 |
Weight not loaded in kg | 1,855 |
---|---|
Weight Max in kg | 2,260 |
Permitted load in kg | 480 |
Permitted Axel load front/rear in kg | 1,125 / 1,200 |
Trunk capacity min.-max. in l | 480 |
Tire front | 275/35 ZR19 (100Y) XL |
---|---|
Tire rear | 285/30 ZR20 (99Y) XL |
Rim front | 9,5J x 19 |
Rim rear | 10,5J x 20 |
Consumption overall in l/100km | 10.2 |
---|---|
Co2 overall in g/km | 232 |
Tank capacity in l | 59 |
Fuel type | Petrol |
---|---|
System power in kW | 375 (510) |
Max. Torque (Nm) | 650 |
Gearbox | 8-speed, automatic |
Drive Type | rear wheel drive |
Cylinder/ Valves per cylinder | 6 / 4 |
---|---|
Technical capacity in cm3 | 2,993 |
Internal combustion engine power in kW | 375 (510) / 6,250 |
Max torque(Nm) per 1/min | 650 / 2750 - 5500 |
Top Speed | 250 |
---|---|
Acceleration | 3.9 |
Length/Width/Height | 4,794 / 1,903 / 1,433 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2068 (1040 / 1028) |
Wheelbase in mm/Wheel turn in m | 2,857 / 12.2 |
Ground clearance in mm | 120 |
Weight not loaded in kg | 1,805 |
---|---|
Weight Max in kg | 2,210 |
Permitted load in kg | 480 |
Permitted Axel load front/rear in kg | 1,080 / 1,180 |
Trunk capacity min.-max. in l | 480 |
Tire front | 275/40 ZR18 (103Y) XL |
---|---|
Tire rear | 285/35 ZR19 (103Y) XL |
Rim front | 9,5J x 18 |
Rim rear | 10,5J x 19 |
Consumption overall in l/100km | 9.6 |
---|---|
Co2 overall in g/km | 221 |
Tank capacity in l | 59 |
Fuel type | Petrol |
---|---|
System power in kW | 353 (480) |
Max. Torque (Nm) | 550 |
Gearbox | 6-speed, manual |
Drive Type | rear wheel drive |
Cylinder/ Valves per cylinder | 6 / 4 |
---|---|
Technical capacity in cm3 | 2,993 |
Internal combustion engine power in kW | 353 (480) / 6,250 |
Max torque(Nm) per 1/min | 550 / 2650 - 6130 |
Top Speed | 250 |
---|---|
Acceleration | 4.2 |
Length/Width/Height | 4,794 / 1,903 / 1,433 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2068 (1040 / 1028) |
Wheelbase in mm/Wheel turn in m | 2,857 / 12.2 |
Ground clearance in mm | 120 |
Weight not loaded in kg | 1,780 |
---|---|
Weight Max in kg | 2,210 |
Permitted load in kg | 505 |
Permitted Axel load front/rear in kg | 1,080 / 1,180 |
Trunk capacity min.-max. in l | 480 |
Tire front | 275/40 ZR18 (103Y) XL |
---|---|
Tire rear | 285/35 ZR19 (103Y) XL |
Rim front | 9,5J x 18 |
Rim rear | 10,5J x 19 |
Consumption overall in l/100km | 10.1 |
---|---|
Co2 overall in g/km | 231 |
Tank capacity in l | 59 |
Lorem
The figures for performance, consumption and CO2 emissions refer to vehicles with standard transmission.
[1] Performance data of petrol engines apply to vehicles using RON 98 fuel. Fuel consumption data apply to vehicles using reference fuels in accordance with EU Regulation 715/2007. Unleaded RON 91 and higher with a maximum ethanol content of 10% (E10) may also be used. BMW recommends RON 95 fuel. For high-performance models, BMW recommends RON 98 fuel.
[2] Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. In addition, NEDC values are deleted from the certificates of conformity as of 1 January 2023 by EC regulation 2022/195. For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp
Further information about fuel consumption and official model-specific CO2 emissions of new passenger cars can be found in the ""Guideline for fuel consumption, CO2 emissions and electric power consumption for new passenger cars"", available free of charge at all points of sale, at the Deutsche Models Treuhand GmbH (DAT), Hellmuth-Hirth-Str. 1, 73760 Ostfildern-Scharnhausen, Germany, and under https://www.dat.de/co2/.
[3] The charging performance depends on the state of charge, ambient temperature, individual driving profile and use of auxiliary consumers. The ranges shown are based on the WLTP best case. The charging times apply to ambient temperatures of 23 degrees Celsius after a preceding drive and may differ depending on the usage behaviour.
[4] The EC unladen weight refers to a vehicle with standard equipment and does not include any optional extras. The unladen weight includes a 90% full tank and a driver weight of 75 kg. Optional equipment may affect the weight of the vehicle, the payload and the top speed if the selected equipment has an impact on the vehicle's aerodynamics.
[5] Provisional figures; any missing figures were unavailable at the time of publication.
The figures for performance, consumption and CO2 emissions refer to vehicles with standard transmission.
(1) Performance data of petrol engines apply to vehicles using RON 98 fuel. Fuel consumption data apply to vehicles using reference fuels in accordance with EU Regulation 715/2007. Unleaded RON 91 and higher with a maximum ethanol content of 10% (E10) may also be used. BMW recommends RON 95 fuel. For high-performance automobiles, BMW recommends RON 98 fuel.
(2) Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. In addition, NEDC values are deleted from the certificates of conformity as of 1 January 2023 by EC regulation 2022/195. For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp
Further information about fuel consumption and official model-specific CO2 emissions of new passenger cars can be found in the ""Guideline for fuel consumption, CO2 emissions and electric power consumption for new passenger cars"", available free of charge at all points of sale, at the Deutsche Automobil Treuhand GmbH (DAT), Hellmuth-Hirth-Str. 1, 73760 Ostfildern-Scharnhausen, Germany, and under https://www.dat.de/co2/.
(3) The charging performance depends on the state of charge, ambient temperature, individual driving profile and use of auxiliary consumers. The ranges shown are based on the WLTP best case. The charging times apply to ambient temperatures of 23 degrees Celsius after a preceding drive and may differ depending on the usage behaviour.
(4) The EC unladen weight refers to a vehicle with standard equipment and does not include any optional extras. The unladen weight includes a 90% full tank and a driver weight of 75 kg. Optional equipment may affect the weight of the vehicle, the payload and the top speed if the selected equipment has an impact on the vehicle's aerodynamics.
(5) Provisional figures; any missing figures were unavailable at the time of publication.
