BMW M3 CS G80 side view driving on race track

THE M3

BMW M

THE NEW BMW 3 SERIES SEDAN M Models: ENGINES & TECHNICAL DATA.

THE M3THE NEW BMW 3 SERIES SEDAN M Models: ENGINES & TECHNICAL DATA.

The new BMW 3 Series Sedan M Models – engines, facts and dimensions.

BMW 3 SERIES SEDAN M MODELS: TECHNICAL DATA.

Select a model
Select Transmission

System Power

Fuel type Petrol
System power in kW 375 (510)
Max. Torque (Nm) 650
Gearbox 8-speed, automatic
Drive Type All wheel drive

Motor

Cylinder/ Valves per cylinder 6 / 4
Technical capacity in cm3 2,993
Internal combustion engine power in kW 375 (510) / 6,250
Max torque(Nm) per 1/min 650 / 2750 - 5500

Performance

Top Speed 250
Acceleration 3.5

Measurements

Length/Width/Height 4,794 / 1,903 / 1,434
Width incl. mirrors (driver / passenger side) in mm 2068 (1040 / 1028)
Wheelbase in mm/Wheel turn in m 2,857 / 12.6
Ground clearance in mm 122
BMW M3 Sedan G80 technical data sketch
BMW M3 Sedan G80 technical data sketch

Weight

Weight not loaded in kg 1,855
Weight Max in kg 2,260
Permitted load in kg 480
Permitted Axel load front/rear in kg 1,125 / 1,200
Trunk capacity min.-max. in l 480

Wheels

Tire front 275/35 ZR19 (100Y) XL
Tire rear 285/30 ZR20 (99Y) XL
Rim front 9,5J x 19
Rim rear 10,5J x 20

Consumption

Consumption overall in l/100km 10.2
Co2 overall in g/km 232
Tank capacity in l 59

System Power

Fuel type Petrol
System power in kW 375 (510)
Max. Torque (Nm) 650
Gearbox 8-speed, automatic
Drive Type rear wheel drive

Motor

Cylinder/ Valves per cylinder 6 / 4
Technical capacity in cm3 2,993
Internal combustion engine power in kW 375 (510) / 6,250
Max torque(Nm) per 1/min 650 / 2750 - 5500

Performance

Top Speed 250
Acceleration 3.9

Measurements

Length/Width/Height 4,794 / 1,903 / 1,433
Width incl. mirrors (driver / passenger side) in mm 2068 (1040 / 1028)
Wheelbase in mm/Wheel turn in m 2,857 / 12.2
Ground clearance in mm 120
BMW M3 Sedan G80 technical data sketch
BMW M3 Sedan G80 technical data sketch

Weight

Weight not loaded in kg 1,805
Weight Max in kg 2,210
Permitted load in kg 480
Permitted Axel load front/rear in kg 1,080 / 1,180
Trunk capacity min.-max. in l 480

Wheels

Tire front 275/40 ZR18 (103Y) XL
Tire rear 285/35 ZR19 (103Y) XL
Rim front 9,5J x 18
Rim rear 10,5J x 19

Consumption

Consumption overall in l/100km 9.6
Co2 overall in g/km 221
Tank capacity in l 59

System Power

Fuel type Petrol
System power in kW 353 (480)
Max. Torque (Nm) 550
Gearbox 6-speed, manual
Drive Type rear wheel drive

Motor

Cylinder/ Valves per cylinder 6 / 4
Technical capacity in cm3 2,993
Internal combustion engine power in kW 353 (480) / 6,250
Max torque(Nm) per 1/min 550 / 2650 - 6130

Performance

Top Speed 250
Acceleration 4.2

Measurements

Length/Width/Height 4,794 / 1,903 / 1,433
Width incl. mirrors (driver / passenger side) in mm 2068 (1040 / 1028)
Wheelbase in mm/Wheel turn in m 2,857 / 12.2
Ground clearance in mm 120
BMW M3 Sedan G80 technical data sketch
BMW M3 Sedan G80 technical data sketch

Weight

Weight not loaded in kg 1,780
Weight Max in kg 2,210
Permitted load in kg 505
Permitted Axel load front/rear in kg 1,080 / 1,180
Trunk capacity min.-max. in l 480

Wheels

Tire front 275/40 ZR18 (103Y) XL
Tire rear 285/35 ZR19 (103Y) XL
Rim front 9,5J x 18
Rim rear 10,5J x 19

Consumption

Consumption overall in l/100km 10.1
Co2 overall in g/km 231
Tank capacity in l 59
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

The figures for performance, consumption and CO2 emissions refer to vehicles with standard transmission.

[1] Performance data of petrol engines apply to vehicles using RON 98 fuel. Fuel consumption data apply to vehicles using reference fuels in accordance with EU Regulation 715/2007. Unleaded RON 91 and higher with a maximum ethanol content of 10% (E10) may also be used. BMW recommends RON 95 fuel. For high-performance models, BMW recommends RON 98 fuel.

[2] Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. In addition, NEDC values are deleted from the certificates of conformity as of 1 January 2023 by EC regulation 2022/195. For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp

Further information about fuel consumption and official model-specific CO2 emissions of new passenger cars can be found in the ""Guideline for fuel consumption, CO2 emissions and electric power consumption for new passenger cars"", available free of charge at all points of sale, at the Deutsche Models Treuhand GmbH (DAT), Hellmuth-Hirth-Str. 1, 73760 Ostfildern-Scharnhausen, Germany, and under https://www.dat.de/co2/.

[3] The charging performance depends on the state of charge, ambient temperature, individual driving profile and use of auxiliary consumers. The ranges shown are based on the WLTP best case. The charging times apply to ambient temperatures of 23 degrees Celsius after a preceding drive and may differ depending on the usage behaviour.

[4] The EC unladen weight refers to a vehicle with standard equipment and does not include any optional extras. The unladen weight includes a 90% full tank and a driver weight of 75 kg. Optional equipment may affect the weight of the vehicle, the payload and the top speed if the selected equipment has an impact on the vehicle's aerodynamics.

[5] Provisional figures; any missing figures were unavailable at the time of publication.

Read more
  • The figures for performance, consumption and CO2 emissions refer to vehicles with standard transmission.

    (1) Performance data of petrol engines apply to vehicles using RON 98 fuel. Fuel consumption data apply to vehicles using reference fuels in accordance with EU Regulation 715/2007. Unleaded RON 91 and higher with a maximum ethanol content of 10% (E10) may also be used. BMW recommends RON 95 fuel. For high-performance automobiles, BMW recommends RON 98 fuel.

    (2) Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. In addition, NEDC values are deleted from the certificates of conformity as of 1 January 2023 by EC regulation 2022/195. For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp

    Further information about fuel consumption and official model-specific CO2 emissions of new passenger cars can be found in the ""Guideline for fuel consumption, CO2 emissions and electric power consumption for new passenger cars"", available free of charge at all points of sale, at the Deutsche Automobil Treuhand GmbH (DAT), Hellmuth-Hirth-Str. 1, 73760 Ostfildern-Scharnhausen, Germany, and under https://www.dat.de/co2/.

    (3) The charging performance depends on the state of charge, ambient temperature, individual driving profile and use of auxiliary consumers. The ranges shown are based on the WLTP best case. The charging times apply to ambient temperatures of 23 degrees Celsius after a preceding drive and may differ depending on the usage behaviour.

    (4) The EC unladen weight refers to a vehicle with standard equipment and does not include any optional extras. The unladen weight includes a 90% full tank and a driver weight of 75 kg. Optional equipment may affect the weight of the vehicle, the payload and the top speed if the selected equipment has an impact on the vehicle's aerodynamics.

    (5) Provisional figures; any missing figures were unavailable at the time of publication.
